EXPLODED VIEW 2C – Dashboard panel and parts FIAT 500F

Select an exploded view number to view the product

EXPLODED VIEW 2C – Dashboard panel and parts FIAT 500F

1

2

3

6

4

5

EXPLODED VIEW 2C – Dashboard panel and parts FIAT 500F

EXPLODED VIEW 2C – Dashboard panel and parts FIAT 500F

1

Dashboard Panel Fiat 500 F – Giardiniera base F

2

Dashboard Knee Pad Pair Fiat 500 F – L – R

Red Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)

Ocher Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)

ed Bordeaux Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)

3

Plastic Storage Tray under Dashboard Fiat 500 F – L – R – Giardiniera base F

6

Speedometer Cluster Rubber Mounting Fiat 500 D (from n.° for spares 648849) – F – R – Giardiniera (from June 1964)

4

Steering Shaft Floor Gasket Fiat 500

5

Dashboard Knee Pad Pair Fiat 500 F – L – R

Red Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)

Ocher Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)

ed Bordeaux Dashboard Knee Pad Pair LHD Fiat 500 F – L – R (Adjustable)
