EXPLODED VIEW 2M – Oil sump FIAT 500N

Select an exploded view number to view the product

ESPLOSO 2M – Coppa olio motore FIAT 500N

ESPLOSO 2M – Coppa olio motore FIAT 500N

3

Sump Gasket Fiat 500 N – D – F – L – R

5,00 €
COD: MOT14

Sump Gasket – Premium Quality – Fiat 500 N – D – F – L – R

12,00 €
COD: MOT14B

Full Engine Gasket Set Fiat 500 N (from engine n.° 135740) – D

60,00 €
COD: MOT1

Full Engine Gasket Set Fiat 500 N (until engine n.° 135739)

75,00 €
COD: MOT1B

1

Engine Oil Sump Fiat 500 N (Adjustable) – D – F – L

75,00 €
COD: MOT273C

2

Engine Oil Sump Drain Plug Fiat 500

3,00 €
COD: MOT274

Engine Oil Sump Drain Plug – Magnetic – Fiat 500

4,00 €
COD: MOT274H

4

5

6

Securing Plate for Engine Oil Sump Fixing Fiat 500 N – D – F – L – R

1,50 €
COD: MOT273B
