EXPLODED VIEW 32M – Tyres and Wheels FIAT 500R

Select an exploded view number to view the product

EXPLODED VIEW 32M – Tyres and Wheels FIAT 500R

1

2

3

4

5

6

7

EXPLODED VIEW 32M – Tyres and Wheels FIAT 500R

EXPLODED VIEW 32M – Tyres and Wheels FIAT 500R

1

Front Brake Drum Fiat 500 N – D – F – L – R

2

Front Grease Cap Fiat 500 N – D – F – L – R

3

Steel Road Wheel Certified 3,5” x 12 Fiat 500 R – Branded “Fergat”

Steel Road Wheel Certified Type “CMR” 4,5” x 12 Fiat 500 N – D – F – L – R

Set of 4 Alloy Wheels Type “Millemiglia” Color Silver Diamond – 4,5” x 12 – Fiat 500 N – D – F – L – R

Set of 4 Alloy Wheels Type “Ray” Color Superlook – 4,5” x 12 – Fiat 500 N – D – F – L – R

Set of 4 Alloy Wheels Type “Grifo” Color Red Diamond – 4,5” x 12 – Fiat 500 N – D – F – L – R

Set of 4 Alloy Wheels Type “Lesmo” Color Silver – 4,5” x 12 – Fiat 500 N – D – F – L – R

4

Wheel Bolt Spring Washer Fiat 500 N – D – F – L – R (until n.° for spares 5.187.044)

5

Wheel Bolt Fiat 500 F – L – R (until n.° for spares 5.187.044)

Tapered Wheel Bolt Fiat 500 R (from n.° for spares 5.187.045)

Wheel Bolt with Increased Lenght Fiat 500 Fiat 500 N – D – F – L – R

Tapered Wheel Bolt with Increased Lenght Fiat 500 N – D – F – L – R

6

Tyre Inner Tube 125/135 – R12 for Fiat 500

Tyre Inner Tube 145/155 – R12 for Fiat 500

7

Tyre 125 – R12 – 62S for Fiat 500

Tyre Cinturato Pirelli 125 – R12 – 62S for Fiat 500

Tyre 135 – R12 – 80 for Fiat 500

Tyre 125 – R12 – 62S with White Wall for Fiat 500

Tyre 145 – R12 – 70 for Fiat 500
