EXPLODED VIEW 33M – Heating system FIAT 500 Giardiniera Base D

Select an exploded view number to view the product

EXPLODED VIEW 33M – Heating system FIAT 500 Giardiniera Base D

17

3

4

6

13

16

16

18

26

27

29

29

EXPLODED VIEW 33M – Heating system FIAT 500 Giardiniera Base D

EXPLODED VIEW 33M – Heating system FIAT 500 Giardiniera Base D

17

Thermostat Housing Heater Hose Pipe Duct Fiat 500 N – D – F – L – Giardiniera (until March 1974)

3

Rear Tunnel Heater Complete Flap Fiat 500

4

6

13

Heater Hose Inside the Front Hood Fiat 500 D – F – L – R – Giardiniera

16

Internal Heater Hose Under Dashboard Fiat 500 D – F – L – R – Giardiniera

16

Internal Heater Hose Under Dashboard Fiat 500 D – F – L – R – Giardiniera

18

Thermostat Housing Heater Hose Pipe Fixing Spring Fiat 500

26

Air Hoses Securing Clip Fiat 500

27

Front Tarred Jute Heater Tube Fiat 500 N – D – F – L – Giardiniera (until March 1974)

29

Pair of Under Dashboard Plastic Heater Vents Fiat 500 R – Giardiniera (from n.° for spares 289432) – adjustable for D – F – L – Giardiniera (until n.° for spares 289431)

Interior Heater Vent Flap Repair Fiat 500 D – F – L – Giardiniera (until n.° for spares 289431)

Gasket for Air Car Heater Vent Fiat 500 D – F – L – R – Giardiniera

29

Pair of Under Dashboard Plastic Heater Vents Fiat 500 R – Giardiniera (from n.° for spares 289432) – adjustable for D – F – L – Giardiniera (until n.° for spares 289431)

Interior Heater Vent Flap Repair Fiat 500 D – F – L – Giardiniera (until n.° for spares 289431)

Gasket for Air Car Heater Vent Fiat 500 D – F – L – R – Giardiniera
